Component Dot Notation with TypeScript

profile picture

Spencer Miskoviak

September 8, 2018 • Last updated on June 11, 2020

Photo by The Creative Exchange

In a previous post and React meetup, I shared several patterns and tools for managing complex features with React and TypeScript. Many of the code samples were using component dot notation, and I briefly mentioned it but did not go in depth about the advantages of using this approach.

This post will dive into those advantages when using component dot notation, highlight a few gotchas, and provide some examples.

What is component dot notation?

As the name suggests, it uses a "dot" to access the property of an object, more commonly referred to as dot notation. However, since this is at the component level (which are still just objects), I prefer "component dot notation" for clarity. A quick example of this is React Context.

const ThemeContext = React.createContext("light");

class App extends React.Component {
  render() {
    return (
      <ThemeContext.Provider value="dark">
        <ThemedButton />
      </ThemeContext.Provider>
    );
  }
}

function ThemedButton(props) {
  return (
    <ThemeContext.Consumer>
      {theme => <Button {...props} theme={theme} />}
    </ThemeContext.Consumer>
  );
}

In this example, ThemeContext is created and is the top-level component. Both the Provider and Consumer are sub-components of ThemeContext accessed using dot notation.

Definitions

These terms will be used throughout the remainder of the post.

  • Top-level component: the actual component that is imported (eg: ThemeContext or Flex). There is only one per set of components.
  • Sub-component: any component accessed using dot notation (eg: ThemeContext.Provider or Flex.Item). There is one or more per set of components.
  • Component dot notation: accessing sub-components from a top-level component using dot notation.

Why use component dot notation?

There are a few key benefits I’ve experienced when using component dot notation to both maintain and consume a set of components.

✏️ Namespacing

As a result of using component dot notation, all sub-components are inherently namespaced by the top-level component. Let’s take a Flex component that wraps CSS flexbox as an example. The top-level component is named Flex with one sub-component: Flex.Item.

import { Flex } from "flex";

function User() {
  return (
    <Flex align="center">
      <Flex.Item shrink={0} grow={0}>
        <Avatar />
      </Flex.Item>
      <Flex.Item shrink={1} grow={1}>
        <UserInfo />
      </Flex.Item>
    </Flex>
  );
}

It does not enforce or stop usage of using Flex.Item outside of Flex, but since it is a sub-component, it does imply to any developer that may be using it that it should only be used as a child of Flex.

🚢 Single Imports

With this technique there is only a single entry point to use the flex components. It doesn’t matter if the Flex.Item component definition and logic is in the same file as Flex, in a sibling file, or in a nested directory. The underlying implementation and file structure can be changed at any time because the only public contract is the export of Flex. This reduces the "public" API surface area as compared to importing every component individually where a change in implementation or file structure will break existing usages.

As a feature evolves over time and pieces are added and removed due to changing requirements, the import can remain unchanged which can reduce noise in changes to imports.

🔍 Discoverability

If there are “n” components in a set, a developer will have to memorize all “n” of those component names to know which to import or go file spelunking to find the component they need. However, with component dot notation, only the top-level component needs to be remembered and all component options will be suggested following the dot! There’s no need to memorize. This also improves discoverability of all components available that may not have been known.

Component dot notation typeahead example in VSCode
Component dot notation typeahead example in VSCode

Examples

There are various practical examples when component dot notation works well. For example, wrapper components like Flex with Flex.Item as a sub-component.

class Flex extends React.Component<Props> {
  public static Item = FlexItem;

  public render() {
    // ...
  }
}

Or slightly more complex components in a design system that maybe have several building blocks. For example, a Table component that has many sub-components such as Table.Row,Table.Cell, and Table.Head that can be used as children only within Table.

class Table extends React.Component<Props> {
  public static Body = TableBody;
  public static Cell = TableCell;
  public static Controls = TableControls;
  public static Head = TableHead;
  public static Header = TableHeader;
  public static Row = TableRow;

  public render() {
    // ...
  }
}

And lastly, it works great for large or complex sets of components, like a Search feature, which has a variety of filter components, pagination, results, etc.

<Search category="Users">
  <Search.Filters>
    <Search.Query title="Search" placeholder="Enter a keyword..." />
    <Search.Facet title="Status" />
    <Search.DateRange title="Application Date" />
  </Search.Filters>
  <Search.PaginationCounter />
  <Search.Sort />
  <Search.Results
    component={UsersCard}
    renderEmpty={UsersNoResults}
    renderLoading={UsersLoading}
  />
</Search>

Gotchas

There are a few "gotchas" you may stumble across that are worth being aware of when using component dot notation.

Higher Order Components

It can be tricky using a higher order component, such as connect from react-redux, on the top-level component. Specifically when using connect, it will hoist all static attributes to the wrapping component (most higher order components do this), but the correct typings will not be preserved. In this case, the higher order component will need to be casted, or if possible, avoid using a higher order component with the top-level component.

Component Display Names

As discussed above, the underlying implementation of the sub-components does not matter. In the case of Flex the Flex.Item component implementation itself could be named NeverCallThisComponentDirectly. This is fine, but the only downside is that in React Devtools, it will be shown as NeverCallThisComponentDirectly, which may be very confusing because it was never called directly.

Example inspecting components with React Devtools using dot notation
Example inspecting components with React Devtools using dot notation

One way around this is to set the displayName on the component to match how it will be used. In this case, the component name remains NeverCallThisComponentDirectly, but now has a display name of Flex.Item.

class NeverCallThisComponentDirectly extends React.Component<Props> {
  public static displayName = "Flex.Item";

  public render() {
    // ...
  }
}

The underlying implementation has not changed at all, but now the component is both used as Flex.Item and correctly seen in React Devtools as Flex.Item.

Example of inspecting components with React Devtools using dot notation with a displayName
Example of inspecting components with React Devtools using dot notation with a displayName

Typing Function Components

All of the examples up to this point are using class components but this same approach can be used with function components. However, it requires explicitly declaring the sub-component in the type declaration.

const Flex: React.FC<Props> & { Item: typeof FlexItem } = () => {
  // ...
};

Flex.Item = FlexItem;

This type declaration uses an intersection to combine the standard React function component type with a type that declares the Item property. This then allows assigning and later using Flex.Item in the same fashion as the class components from above.

Tree Shaking

One disadvantage of this approach is that it can "break" tree shaking. At a high level, tree shaking works by removing code that is not imported nor used. Since the top-level Search component imports and exposes all sub-components, they will all be included even if never used. However, if this is an actual problem it probably suggests an overuse of component dot notation or the set of components are not related.

Final thoughts

Component dot notation can be a useful technique when working with a set of components. It minimizes the API surface area to a single export, keeps the import simple and improves the discoverability of available sub-components.
