Tools for an evolving Design System

profile picture

Spencer Miskoviak

October 14, 2020

Photo by Shivendu Shukla

Design systems are often discussed and treated as if they are a static thing. However, a "healthy" design system will likely be constantly evolving. This could be the result of new data such as user research, new learnings about component APIs, new ideas discovered in the community, a new use case, or changing requirements.

Problems

Although this evolution is likely beneficial and results in a better system, it can sometimes be challenging to make these changes.

Renamings

The first general problem is needing to rename components, props, or something else in the system that is exposed.

For example, maybe after using a component for a while you realize there is a better, more meaningful name. This initially can seem like a simple change until you realize it's used across hundreds of files in a number of different ways. Let's say there is a component named Box that needs to be renamed to Card. This requires updating imports and usages.

We could try doing a global search and replace on a string with a single import.

import { Box } from "design-system";

What about cases with multiple imports?

import { Avatar, Box, Button } from "design-system";

We might consider a more sophisticated global search and replace using regex. What about cases where there are many things imported and the imports are each on a newline?

import {
  Avatar,
  Box,
  Button,
  // ...
} from "design-system";

What seemed like a simple rename now has all sorts of cases and we only covered the imports, not the actual usages. For example, a global search and replace for <Box (opening JSX) would also match something like <BoxContainer which shouldn't be renamed.

You can imagine similar problems when renaming props, especially ones with common names such as type. How would you begin searching for the type prop on only one specific component?

Evolving patterns

A related but different problem is when a new component or use case is added and supported by the system.

Often, the existing patterns can't be updated mechanically as in the previous example. Instead, they need to be updated manually. Often, this migration is too much work to do all at once upfront so it needs to be migrated over time. However, it can be easy to forget when working on some feature to also update the legacy pattern to instead use the new component or prop. How can we encourage these patterns to be updated over time?

Tools

There are a set of tools that can be helpful in making these type of system-wide changes with ease and accuracy. Without these tools, these types of changes can become a big headache, or get skipped entirely.

TypeScript

The first tool is TypeScript. This one can be tricky, because to really benefit from it the whole codebase needs to be TypeScript.

If that's the case, the component or prop can selected and renamed using the "Rename Symbol" option in VSCode. This renames all usages across files.

VSCode: Rename Symbol

This is only one of the many benefits of TypeScript. However, it's not feasible for everyone to either switch to TypeScript, or quickly migrate the entire codebase. Fortunately, there's another tool that can be used.

jscodeshift

Codemods are like a supercharged search and replace because they provide a lot more context. A generic search is only matching on a string. However, codemods operate on the actual AST (abstract syntax tree) that underlies the source code. This means that you can much more accurately operate on a specific type of node, rather than any string that matches. For example, it's possible to find opening JSX elements with the name Box, or opening elements with the name Box and narrow down to only it's type prop.

jscodeshift is a specific tool for running these codemods on JavaScript and TypeScript files. If you'd like to see a more in depth example, I've previously written about creating a custom transform for jscodeshift.

ESLint

The two previous tools are primarily used for renaming things or other mechanical changes. Linting is a useful tool when it is easy to tell what needs to be updated, but maybe hard to mechanically do the update.

For example, say when first building out a system you want to convert elements with certain class names to the corresponding component.

// Old element that needs to be converted:
<div className="card" />

// Converted to component:
<Card />

This example is fairly trivial and could likely be done with a codemod, but you can imagine a case where it's maybe a group of related elements that are now replaced by a single component. Or, maybe the existing usage had custom styles that need to be resolved when making the update.

A custom linting rule could be made that looks for any className prop with a card class name. This rule could be set to warn, so as pieces of code are touched the warnings will be surfaced and fixed. This can be more effective than written or verbal communication that can easily forgotten, whereas an inline warning is a more contextual reminder. It also provides a running list of how many places still need to be migrated. Once all violations have been fixed, the rule can be set to error to prevent regressions to previous patterns, or entirely removed.

However, you want to be careful of linting fatigue. Adding too many rules, triggering false positives or negatives, or being too intrusive can be detrimental.

Conclusion

When evolving a design system there are a number of changes that seem simple, but can be challenging due to both the number of uses and unique ways of using it. Hopefully the next time you need to make a system-wide change that faces one of these problems, you're better equipped to know which tools are at your disposal.
